Plough Shear Mixer

The Plough Shear Mixer is a state-of-the-art mixing machine designed to handle both dry and wet materials with precision and efficiency. Widely used in industries such as pharmaceuticals, chemicals, cosmetics, ceramics, dyestuffs, and food products, this mixer ensures an even spread of materials, delivering consistent and high-quality results.

Key Features:

• Effective Mixing: The Plough Shear Mixer uses specially designed shovels that move materials around the mixing drum, ensuring uniform mixing. The shovels are engineered with wide ends and pointed tips, which allow them to penetrate and move materials effectively, providing an even spread throughout the drum.
• Versatile Applications: Ideal for a variety of industries, this mixer is capable of handling different materials, including powders, granules, and even wet substances. It is perfect for applications where consistent mixing is crucial for product quality.
• Robust Construction: Built with durability in mind, the Plough Shear Mixer is available in two models:
  • GMP Model: Fully constructed from stainless steel, ensuring the highest level of hygiene and corrosion resistance, making it ideal for pharmaceutical and food applications.
  • STD Model: Features stainless steel for product contact parts and mild steel for non-contact parts, providing a cost-effective solution without compromising on performance.

Model Specifications:

• PSM-25L:
  • Working Capacity: 20 LTRS (10/5 KGS)
  • Gear Size: V400
  • Main Motor: 3 HP at 1500 RPM / 5 HP at 750 RPM
  • Approximate Weight: 800 KG
• PSM-50L:
  • Working Capacity: 40 LTRS (20/10 KGS)
  • Gear Size: V500
  • Main Motor: 5 HP at 1500 RPM / 7.5 HP at 750 RPM
  • Approximate Weight: 1100 KG
• PSM-100L:
  • Working Capacity: 80 LTRS (40/20 KGS)
  • Gear Size: V500
  • Main Motor: 7.5 HP at 1500 RPM / 10 HP at 750 RPM
  • Approximate Weight: 1800 KG
• PSM-150L:
  • Working Capacity: 120 LTRS (60/30 KGS)
  • Gear Size: V600
  • Main Motor: 10 HP at 1500 RPM / 15 HP at 750 RPM
  • Approximate Weight: 2300 KG
• PSM-250L:
  • Working Capacity: 200 LTRS (100/50 KGS)
  • Gear Size: V700
  • Main Motor: 22.5 HP at 1500 RPM / 30 HP at 750 RPM
  • Approximate Weight: 3000 KG
• PSM-300L:
  • Working Capacity: 240 LTRS (120/60 KGS)
  • Gear Size: V700
  • Main Motor: 22.7 HP at 1500 RPM / 30 HP at 750 RPM
  • Approximate Weight: 3600 KG
• PSM-400L:
  • Working Capacity: 320 LTRS (160/80 KGS)
  • Gear Size: V800
  • Main Motor: 35 HP at 1500 RPM / 40 HP at 750 RPM
  • Approximate Weight: 3600 KG
• PSM-500L:
  • Working Capacity: 480 LTRS (240/120 KGS)
  • Gear Size: V1000
  • Main Motor: 40 HP at 1500 RPM / 50 HP at 750 RPM
  • Approximate Weight: 4700 KG
• PSM-700L:
  • Working Capacity: 560 LTRS (280/140 KGS)
  • Gear Size: V1000
  • Main Motor: 40 HP at 1500 RPM / 50 HP at 750 RPM
  • Approximate Weight: 4700 KG
• PSM-800L:
  • Working Capacity: 640 LTRS (320/160 KGS)
  • Gear Size: V1000
  • Main Motor: 50 HP at 1500 RPM / 60 HP at 750 RPM
  • Approximate Weight: 4700 KG
• PSM-1000L:
  • Working Capacity: 800 LTRS (400/200 KGS)
  • Gear Size: V1200
  • Main Motor: 63 HP at 1500 RPM / 85 HP at 750 RPM
  • Approximate Weight: 5600 KG

The Plough Shear Mixer is engineered for reliability and efficiency, making it a critical component in any production line where precise and consistent mixing is required.
